Método de impressão
Direct Thermal
Thermal Transfe
Resolução de impressão
203 dpi (8 dots/mm)
Velocidade de impressão
2~ 3 ips (51~76mm/s)
Comprimento de impressão
Máximo 43”(1092mm)
Largura de impressão
Máximo 4.16”(105mm)
Processamento
Processador RISC 32 bits
Media gap/ black line reflective sen
Memória
8MB DRAM (7MB disponível para o usuário)
4MB Flash ROM (3MB disponível para o usuário)
Interface de operação
LED Power
LED Ready
Botão de alimentação
Sensor de mídia
Media gap/ black line reflective sensor, ribbon end sensor
Porta de comunicação
1x paralela Centronics
1x RS-232
1x USB
Fontes
Internal character sets standard
5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm)
Internal fonts are expandable up to 24x24
4 direction 0 ~ 270 rotation
Soft fonts are downloadable, Ability to print Windows True Type Fint easily(OS-2140D only)
Códigos de barra 1D
PPLA:Code 39, UPC-A, UPC-E,Code 128 subset A/B/C, EAN-13, EAN-8, HBIC, Codabar, Plessey, UPC2, UPC5, Code 93, Postnet, UCC/EAN-128,
UCC/EAN-128 K-MART, UCC/EAN-128 Random Weight, Telepen, FIM,Interleave 2 of 5 (Standard/with modulo 10 checksum/with human readable
check digit/with modulo 10 checksum & shipping bearer bars), GS1 Data bar (RSS)
PPLB:Code 39 Std. & Extended, UPC-A, UPC-E, Matrx 2 of 5, UPC-Interleaved 2 of 5,Code 39 with check sum digit, Code 93, EAN-13, EAN-8
(Standard, 2 /5digit add-on), Codabar, Postnet, Code128 subset A/B/C, Code 128 UCC (shipping container code), Code 128 auto, UCC/EAN code
128 (GS1-128),
Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, German Postcode, Matrix 2 of 5,UPC
Interleaved 2 of 5, EAN-13 2/5 digit add-on, UPCA 2/5 digit add-on, UPCE 2/5 digit add-on, GS1 Data bar (RSS)
PPLZ:Code39, UPC-A, UPC-E, Postnet, Code128 subset A/B/C, Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human
readable check digit, Code 93, Code 39 with check sum digit, MSI, EAN-8, Codabar, Code 11, EAN-13, Plessey, GS1 Data bar (RSS), Industrial 2 of
5, Standard 2 of 5, Logmars
Códigos de barra 2D
PPLA /PPLZ : MaxiCode, PDF417,Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec, Micro PDF 417
PPLB: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec
Gráficos
PPLA: PCX, BMP, IMG, HEX ,GDI
PPLB: PCX, Binary raster , GDI
Emulação
PPLA / PPLB
Compatibilidade
Windows XP
Windows Vista
Windows 7
Windows 8
Programas utilitários
Printer Utility
Font Utility
Tipos de mídias suportados
Roll-feed,
die-cut,
continuous,
fan-fold,
tags,
ticket in thermal paper,
plain paper
Dimesões da impressora
Largura 186mm
Altura 165mm
Profundidade 278mm
Peso
Aproximadamente 2KG
Energia
Fonte de alimentação bivolt 100V~240 volts
Garantia
Garantia e suporte de 3 meses da Argox do Brasil
